Sản phẩm của chúng tôi
Thiết bị mạng SWITCH HP - Smart-managed HP 1810-8 Switch - J9800A
Chi tiết:
Smart-managed HP 1810-8 Switch - J9800A
7 RJ-45 autosensing 10/100 ports + 1 RJ45 10/100/1000 ports
Smart-managed HP 1810-8 Switch - J9800A
7 RJ-45 autosensing 10/100 ports + 1 RJ45 10/100/1000 ports
| Technical specifications | |
| Ports | 7 RJ-45 autosensing 10/100 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX) |
| Duplex: half or full; 1 RJ-45 autosensing 10/100/1000 port (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T) | |
| Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only; Supports a maximum of 7 autosensing 10/100 ports plus 1 autosensing 10/100/1000 ports | |
| Mounting | wall, desktop, and under-table mounting |
| Memory and processor | 128 MB RAM, packet buffer size: 512 KB, 8 MB flash |
| Latency | 100 Mb Latency: < 3.3 µs (64-byte packets) |
| Throughput | up to 2.5 million pps |
| Management features | Web browser |
| Switching capacity | 3.4 Gbps |
| Connectivity and communications | |
| Denial of service protection | CPU DoS Protection |
| General protocols | IEEE 802.1p Priority; IEEE 802.1Q VLANs; IEEE 802.1W Rapid Spanning Tree Protocol; IEEE 802.3ad Link Aggregation Control Protocol (LACP); IEEE 802.3az Energy Efficient Ethernet; IEEE 802.3x Flow Control; RFC 1534 DHCP/BOOTP Interoperation; RFC 2030 Simple Network Time Protocol (SNTP) v4 |
| Network management | IEEE 802.1AB Link Layer Discovery Protocol (LLDP) |
| Power and operating requirements | |
| Power consumption | 4.8 W (maximum) |
| Input voltage | 100-240 VAC |
| Input operating current | .5 A |
| Input frequency | 50/60 Hz |
| Safety | UL 60950-1; IEC 60950; EN 60950 |
| Electromagnetic compatibility | EN 55022 Class A; CISPR 22 Class A; VCCI V-3; FCC (CFR 47, Part 15) Subpart B Class A; VCCI V-4 |
| Operating temperature range | 0 to 40°C |
| Operating humidity range | 15 to 95% @ 104°F (40°C) |
| Operating altitude | up to 3 km |
| Acoustic pressure emissions | Power: 0 dB, no fan |
| Heat dissipation | 204 BTU/hr (215.22 kJ/hr) |
| Immunity standard | IEC 61000-4-2; IEC 61000-4-3; IEC 61000-4-4; IEC 61000-4-5; IEC 61000-4-6; IEC 61000-4-8; IEC 61000-4-11; EN 61000-3-2; EN 61000-3-3 |
| Dimensions and weight | |
| Minimum dimensions (W x D x H) |
20.14 x 11.81 x 4.39 cm |
| Weight | .35 kg |
- Hàng chính hãng HP.
- Bảo hành: 03 năm
